Meets or exceeds the dry or wet electrical requirements of:
- IEC 62192:2009
- ASTM F1701-12
Arc-Flash rated
- Resistant to 40 cal/cm2 (category 4)
Features
- Unique insulating properties
- Cleanable and easy to maintain and test
- Exceptionally low leakage current, whether dry or wet
- Protection from high fault current
- High strength
- Low elongation
- Lightweight and low volume
- Fully sealed and hydrophobic
- Smooth surface
- High abrasion resistance
- Easy to deploy
- Excellent resistance to UV
SPECIFICATIONS:
- Rope Diameter: 1/4” (6 mm)
- Mesh Size: 2’-6” x 2’-6” (0.75 m x 0.75 m)
- Mesh break strength: 600 lb (272 kg) each
- Thimble to thimble break strength: 2 000 lb (907 kg)
- Terminations: Stainless steel thimble every 5’ (1.5 m) on 2 sides
- Colour: Black rope with orange junction clips
- Weight: 185 lb (84 kg) for 70‘ x 100‘ (21 m x 30.5 m) net
-
Standard dimensions:
- 70’ x 100’ (21 m x 30.5 m)
- 70’ x 150’ (21 m x 45.7 m)
- 70’ x 200’ (21 m x 61 m)
Note: Available in other widths, lengths, mesh sizes.
